CTS Off-highway Equipment Electric Loader Agricultural Machinery 614.4V 282KWh Lifepo4 Battery

Name: CTS Offhighway Equipment Electric Loader Agricultural Machinery 6144V 282KWh Lifepo4 Battery
Brand: CTS Battery
Price: 120 USD

Brand Name : CTS Battery

Model Number : CTS-LFP614105

Certification : CE, UN38.3, MSDS

Place of Origin : China

MOQ : 2 SETS

Price : USD120-USD200/KWH

Payment Terms : T/T,Western Union,L/C

Supply Ability : 6000 SETS/YEAR

Delivery Time : 60-70 DAYS

Packaging Details : Plywood case

Battery Product : 614.4V 460Ah 282.6kWh

Application : Electric Farm Tractor Agricultural BEVs Vehicle PEV, Electric tractor

Array Mode : 8 battery modules+ a PDU box

PDU Box : Including EVCC, relays, master BMS, precharge resistor and fuses and other conponents

Charge Power : Max 200kW cont. with liquid cooling

Charge Standard : CCS1/CCS2 DC fast charging

Discharge Power : 282kW cont. 560kW peak for 30 sec

Contact Now

CTS Off-highway Equipment Electric Loader Agricultural Machinery 614.4V 282KWh Lifepo4 Battery

NO.	Specification of 614.4V 460Ah 282.6KWh Lifepo4 Battery
1	Rated Voltage	614.4v
2	Rated Capacity	460Ah
3	Array Mode	2P 192S
4	Total Energy	282.6kWh
5	Continous Discharge Current	400A Max at 25℃
6	Peak Discharge Current	800A within 5s
7	Recommend Charge Current	Max 100A
8	Communicate Peotocol	CAN BUS
9	Dimension	8 modules in total +a PDU box
10	Estimated Weight	about 1830kg (without installation brackets)
11	IP Proetction	IP67
12	Cooling Method	Liquid Cooling
13	Heating Method	Charge PI Heating
14	Dimension with brackets	8(L1060W630H240mm) +a PDU (L500W400*H300mm)

Standard EV Battery Module facts:

uD83DuDC77PACK System Core Technology uD83DuDC77Compact + Lightweight Design uD83DuDC77Patented Smart Thermal Liquid Technology uD83DuDC77Modular Design + Single Module Drivable uD83DuDC77The all parts in the module is standard parts which are molded parts uD83DuDC77Cell Core Technology uD83DuDC77Power type Li-ion battery has long cycle life and fast charging-discharging. It can keep the mobility of electric vehicles.

Why choose this Standard EV Battery Module?

✅SOC Calculation: Real time dynamic calibration Vehicle operation condition wasconsidered Multi-method combination High accuracy measurement of thecell Voltage /temperature/pack current Amount of data from experiment✅Faults Diagnosis: Insulation & water leakage Cell voltage out of range High/low temperature Communication faults Contactor weld Power connection Temperature sensor faults

Electric vehicle lithium-ion battery - CTS battery

Electrical diagram of lithium battery system in standard box Two way high voltage input, doublegun charging Two way hight voltage output-water cooling compressor output; motor driving output;Single way low voltage output ,communicate with the whole vehicle!
